Huck Pneudraulic Tooling
Huck2025
Huck2025
The Model Huck2025 Installation Tool is shipped with a plastic plug in the air inlet connector. The connector has 1/4-18 female pipe threads to accept the air hose fitting. Quick disconnect fittings and 1/4” inside diameter air hose are recommended. An air supply of 90 - 100 psi capable of 20 CFM must be available. Air supply should be equipped with a filter-regulator-lubricator unit.
Huck246
Huck246
The Model Huck246 Installation Tool is shipped with a plastic plug in the air inlet connector. The connector has 1/4-18 female pipe threads to accept the air hose fitting. Quick disconnect fittings and 1/4” inside diameter air hose are - recommended. An air supply of 90 - 100 psi capable of 20 CFM must be available. Air supply should be equipped with a filter-regulator-lubricator unit.
Huck256
Huck256
The Model Huck256 Installation Tool is shipped with a plastic plug in the air inlet connector. The connector has 1/4-18 female pipe threads to accept the air hose fitting. Quick disconnect fittings and 1/4” inside diameter air hose are recommended. An air supply of 90-100 psi capable of 22.4 CFM must be available. Air supply should be equipped with a filter-regulator-lubricator unit.
Huck244BT
Huck244BT
The Model Huck244BT Installation Tool is shipped with a plastic plug in the air inlet connector. The connector has 1/4-18 female pipe threads to accept the air hose fitting. Quick disconnect fittings and 1/4” inside diameter air hose (1) are recommended. An air supply of 90-100 psi capable of 6.3 CFM must be available. Air supply should be equipped with a filter-regulator- lubricator unit.
Huck256BT
Huck256BT
The Huck256BT Tool is designed for rapid installation of Huck BobTail fasteners. It features optimum stroke for one-cycle installation of fasteners, and minimal moving parts.
The Huck256BT installs both 7.9mm and 9.5mm BobTail Fasteners
* NOTE: For additional tool details, refer to the specific fastener brochure or visit AFSHuck.net.
Huck Hydraulic Tooling
2480
2480
The Model 2480 is a very lightweight tool which provides for the high-speed installation of a wide range of HuckBolt and Huck blind bolt fasteners. The tool has only one moving part, resulting in outstanding reliability and minimal maintenance. The tight centerline-to- edge measurement of the Model 2480 and its light weight (2.21 pounds) allow for its use in limited clearance areas.
2581
2581
The 2581series, with appropriate nose assemblies, install a wide range of Huck blind fasteners and HUCKBOLT® fasteners. These lightweight and compact tools are particularly adapted to installing fasteners in limited clearance areas. Each tool is complete with hydraulic hoses and couplings, electric switch and cord.
An unloading valve, designed to relieve hydraulic pressure at end of the PULL stroke, is positioned by the piston. The end of the piston rod is threaded. A retaining nut and stop are included for attaching a nose assembly
2600
2600
The Model 2600 is a lightweight and versatile installation tool designed to use with a wide range of Huck blind fasteners and HuckBolt® fasteners. The tool’s compact size allows it to fit into limited clearance applications, while its light weight provides for outstanding operator productivity.
2620
2620
The Model 2620 is a lightweight and versatile installation tool designed to use with a wide range of Huck blind fasteners and HuckBolt fasteners. The tool’s compact size allows it to fit into limited clearance applications, while its light weight provides for outstanding operator productivity.
2620-PT
2620-PT
The Model 2620-PT is a pass-through hydraulic tool. The tool is capable of installing 1/2" diameter Huck lockbolts and blind bolts. This tooling is fully compatible with existing pass-through nose assemblies.
2624
2624
The 2624 is a lightweight ergonomic .for installing 5/8” and 16MM diameter Huck lockbolts and blind bolts. This line of tooling is fully compatible with existing nose assemblies
3585
3585
Offering durable construction, advanced hydraulics, and safe, ergonomic design, the 3585 installation tool is easy-to-hold and efficient to use. An improved piston and cylinder design promote longer life. In addition, the nose adapter can be removed through the back of the tool for ease of repair. The 3585 is ideal for installation of all -16 (1/2”) to -24 (3/4") pintail-style lockbolts. Stroke: 1.812”; Weight: 19 lbs.
2630
2630
The 2630 is a lighter weight, ergonomically designed replacement for the 506 Tool, utilising the same Nose Assemblies. The 2630 tool has only one moving part for maximum reliability and the sealing configuration is designed to minimise service requirements.
507
507
The Model 507 is a heavy-duty tool sized for the installation of 1" C50L HuckBolt fasteners. This rugged tool provides high-speed installation in a wide range of production applications.
6304&7304&9304
6304&7304&9304
Huck models 6304, 7304, 8304, and 9304 Hydraulic Installation Tools are used to install C50L and M50L HUCK- BOLT® Fasteners. Each tool model has the same eccentric configuration to install fasteners in limited clearance applications. The four tool models vary in size and pull capacity. Each model has a built-in nose assembly designed to install a specific size fastener.
BTT25
BTT25
The BTT25 was developed specifically for installation of BobTail 12mm to 14mm fasteners. As with all BTT (BobTail Tool) Tools, the BTT25 is configured for limited clearance applications. The unique hydraulic piston arrangement allows for a small diameter cylinder, which gives a small center-to-edge distance along the complete length of the tool.
BTT35
BTT35
The BTT35 was developed specifically for installation of the BobTail 16mm fastener. As with all BTT (BobTail Tool) Tools, the BTT35 is configured for limited clearance applications. The unique hydraulic piston arrangement allows for a small diameter cylinder, which gives a small center-to-edge distance along the complete length of the tool.
BTT57
BTT57
The BTT57 was developed specifically for installation of the BobTail 20mm fastener. As with all BTT (BobTail Tool) Tools, the BTT57 is configured for limited clearance applications. The unique hydraulic piston arrangement allows for a small diameter cylinder, which gives a small center-to-edge distance along the complete length of the tool.
SFBTT8
SFBTT8
Huck’s proprietary, advanced swageforward tooling for BobTail fasteners, the SFBTT series, makes the installation process quicker and easier by reducing the force required to install each fastener. More compact and lighter weight than previous Huck lockbolt production tooling, BobTail installation tools also offer greater operator flexibility as well as extended reach into difficult areas.For tight, space-constrained applications, swageforward BobTail tools allow the operator to position his or her hand at a safe distance from the working structure during installation.
SFBTT20
SFBTT20
Huck’s proprietary, advanced swageforward tooling for BobTail fasteners, the SFBTT series, makes the installation process quicker and easier by reducing the force required to install each fastener. More compact and lighter weight than previous Huck lockbolt production tooling, BobTail installation tools also offer greater operator flexibility as well as extended reach into difficult areas.For tight, space-constrained applications, swageforward BobTail tools allow the operator to position his or her hand at a safe distance from the working structure during installation.
SF20
SF20
Huck’s proprietary, advanced swageforward tooling for BobTail fasteners, the SFBTT series, makes the installation process quicker and easier by reducing the force required to install each fastener. More compact and lighter weight than previous Huck lockbolt production tooling, BobTail installation tools also offer greater operator flexibility as well as extended reach into difficult areas.For tight, space-constrained applications, swageforward BobTail tools allow the operator to position his or her hand at a safe distance from the working structure during installation.
SF46
SF46
Huck’s proprietary, advanced swageforward tooling for BobTail fasteners, the SFBTT series, makes the installation process quicker and easier by reducing the force required to install each fastener. More compact and lighter weight than previous Huck lockbolt production tooling, BobTail installation tools also offer greater operator flexibility as well as extended reach into difficult areas.For tight, space-constrained applications, swageforward BobTail tools allow the operator to position his or her hand at a safe distance from the working structure during installation.
* NOTE: For additional tool details, refer to the specific fastener brochure or visit AFSHuck.net.
AVK Pneudraulic Tooling
AR Tooling
AR Tooling
AVK HAND OPERATED PNEUMATIC TOOL
AVK has selected the ARO Brand Pneumatic Tool for its ergonomic design and outstanding dependability. The rocker style forward and reverse trigger is easy and comfortable to use.
The AVK pneumatic tool features a Quick-Change thread adaption kit. This patented* feature allows for easy access to the thread size component parts. AVK’s Pneumatic tools provide the highest RPM for the thread size selected resulting in optimum installation speed.
AS Tooling
AS Tooling
AVK HAND OPERATED PNEUMATIC TOOL
AVK has selected the ARO Brand Pneumatic Tool for its ergonomic design and outstanding dependability. The rocker style forward and reverse trigger is easy and comfortable to use.
The AVK pneumatic tool features a Quick-Change thread adaption kit. This patented* feature allows for easy access to the thread size component parts. AVK’s Pneumatic tools provide the highest RPM for the thread size selected resulting in optimum installation speed.
AT AW Tooling
AT AW Tooling
AVK HAND OPERATED PNEUMATIC TOOL
AVK has selected the ARO Brand Pneumatic Tool for its ergonomic design and outstanding dependability. The rocker style forward and reverse trigger is easy and comfortable to use.
The AVK pneumatic tool features a Quick-Change thread adaption kit. This patented* feature allows for easy access to the thread size component parts. AVK’s Pneumatic tools provide the highest RPM for the thread size selected resulting in optimum installation speed.
AL AK AH AP AO Tooling
AL AK AH AP AO Tooling
AVK HAND OPERATED PNEUMATIC TOOL
AVK has selected the ARO Brand Pneumatic Tool for its ergonomic design and outstanding dependability. The rocker style forward and reverse trigger is easy and comfortable to use.
The AVK pneumatic tool features a Quick-Change thread adaption kit. This patented* feature allows for easy access to the thread size component parts. AVK’s Pneumatic tools provide the highest RPM for the thread size selected resulting in optimum installation speed.
AVK5500
AVK5500
AVK OST™ PNEUMATIC RAPID INSERT TOOL - AVK5500
Time is money; and to reduce your installation cost with a rapid sure shot installation tool, AVK is pleased to introduce the AVK One-Set™ Tool (OST™) insert installation system. Our OST™ is a multi-stroke and pull to pressure insert tool designed to meet any installation criteria.
OST™ is s a light weight 4.4 pound ergonomic installation tool allowing you to select your Placement Method, Stroke or Pressure. Combined with our insert auto-feed threading system, and single trigger installation, this tool will offer a new standard in fast and easy insert installation for your product assembly.
* NOTE: For additional tool details, refer to the specific fastener brochure or visit AFSHuck.net.
GAIPNAIL Pneudraulic Tooling
211
211
Rugged, Ergonomic and Portable
The Gripnail 211 Air Tool is used for driving fasteners that require a precise, regulated, simple impact. This trigger activated tool has a safety interlock that prevents accidental firing and impact is adjusted with the incoming air pressure. The lightweight, ergonomic design has a comfortable, cushioned handle and includes The Freedom Swivel® air coupler to help keep the air hose from interfering with the operation.
*
Powerig
Huck32-002
Huck32-002
The electrically operated HK32-002 Powerig is designed to operate Huck hydraulic Installation Tools, (See Utilisation).
The maximum hydraulic Pull Pressure and Return Pressure is 580 bar (8410 psi).The Powerig hydraulic Directional Valves plus control circuits, are powered from a 24 Volt DC remote circuit activated by the Tool Trigger via the PLC.
Huck940-220
Huck940-220
The Model 940-220 Powerig® is a portable unit sized for moderate production and repair applications. This unit features rugged construction for durability in the field, and the choice of 220 Volt AC power. The Model 940-220 includes a handle for easy transport, simple adjustable hydraulic outputs and quick-connect couplers for connecting installation tool hoses.
SPECIFICATIONS
Width:10.5 in.
Length:12.5
Height:18 in.
Weight:74.5 lbs. operational, 66 lbs. w/o hydraulic fluid
Power:electric, 220 volts, single phase
Flow Rate:70 cu. in./min. @ 5,000 psi
Reservoir Capacity:1.5 gallons
Options: 220V, 60/50 hertz single phase, 250VDC, direct current
Huck918
Huck918
The Model 918 Powerig® is the largest hydraulic unit offered by Huck. Sized for high production applications, the unit can operate up to two tools independently. This electrically powered model also delivers sufficient power to operate the tools up to 100 feet away. A 22-gallon reservoir stores hydraulic fluid, with a filter-strainer in the suction line to assure clean, filtered fluid.
SPECIFICATIONS
Width: 25 in.
Length: 44 in.
Height: 30 in.
Weight:780 lbs. operational, 585 lbs. w/o hydraulic fluid
Power: electric, 220 or 440 volts 3 phase
Flow Rate : 2.0 gpm per tool station
Reservoir Capacity: 22 gallons
Huck918-5
Huck918-5
The Model 918-5 POWERIG® is the largest hydraulic unit offered by HUCK. Sized for high production applications the unit can operate up to three tools independently. This electrically powered model also delivers sufficient power to operate the tools up to 100 feet away. A 22-gallon reservoir stores hydraulic fluid, with a filter-strainer in the suction line to assure clean, filtered fluid.
*
